Supermaster Two Platen Series

Advanced Servo Hydraulic Injection Moulding Machines

Time Tested

First launched in 2008 The SM Two Platen Servo Drive injection moulding series has gone over relentless improvements over the past years and remains one of our flagship machine series.

Tried & Proven

Hundreds of presses from the SM700 up to SM6500 tons are currently running reliably for customers around the world in every industry.
They deliver high precision, high stability, high speed, and ultimate mould protection without any of the traditional compromises.

Clamping – from 700 to 6500 tons!

Major Advantages of SM-TP Machines

  • 1

    Incredible Speeds:

    Up to 750mm/s speed in Clamp open/close.
  • 2

    High Efficiency Innovance Servo Motors:

    Reducing energy consumption up to 80%, bringing high precision and super low noise operation.
  • 3

    Unique Mix and Match Capability:

    You may select from 14 sizes of different clamping units and match them with 29 different injection units.
  • 4

    Speedy Setup:

    Fast die height and clamping setup technology. (Die height adjustment in only 20 seconds).
  • 5High Speed Clamping Pressure Build Up.
  • 6High Pressure Injection and Fast Speed Recovery.
  • 7Optional Ejector on the Fly.

European Specs

  • 1

    EUROMAP STANDARD:

  • Hole pattern and ejector pattern according to Euromap standards*.
  • T-slot or other patterns possible on request.
*Hole pattern/ejector pattern may differ from standard due to platen design.
  • 2

    EUROPEAN COMPONENTS:

    Standard European components:
  • Hydraulic valves: Bosch Rexroth or Vickers
  • Hydraulic pump: Eckerle
  • Linear transducers: Gefran or Novotechnik
  • Electrical components: Siemens, Schneider, Telemechanique, PILZ

CB-mold 800

German engineering-Beckhoff Controls

Customized for the SM-TP series

Controls

  • 1

    BECKHOFF – Made in Germany:

    Powered by German engineering-Beckhoff controls and customized for the SM-TP machines.
  • 2

    User Friendly Touch-screen:

    15-inch multi-touch screen display provides user-friendly operation and a comprehensive list of settings and options.
  • 3

    Intelligent Control System:

    Can-Bus based I/O creates the fastest response and reliability.
  • 4

    Flexibility:

    Isolated and expandable I/O for special operations/options/Automations.
  • 5

    Save your Data:

    Unlimited mould data saving using a thumb drive.
  • 6

    Advanced Reports:

    Provides various reports for production, settings, alarm records and logs of operational settings.
  • 7

    Network ready:

    Ready to plug into a cloud-based service and participate in the IoT at the very fundamental level.

Injection

  • 1Injection pressure from 18000PSI up to 28000PSI provided by dual-parallel high-pressure injection cylinders and shot size starting from 81oz up to 3812oz.
  • 2Injection unit Swivel for easy barrel and screw maintenance.
  • 3Linear bearing based injection unit to evenly distribute the stress of injection pressure for raising the machine repeatability and reliability.
  • 4High Torque fast speed hydraulic motor or E-drive for screw rotation.
  • 5Back pressure controlled by proportional or LDVT valves to provide the finest contrast in recovery.
Photo Gallery
CBmolc800 German engineering-Beckhoff Controls
Enlarged End-cap design to ease the maintenance of the screw tip assembly and nozzle.
Standard SPI/CE based electric safety features.
Beckhoff-Germany Can-Bus based controller featuring fully isolated I/O.
Latest technology of Servo system providing up to 80% energy saving, precision and low noise operation, including SPI/CE based layout and wiring.
Clamping system is being tested for multiple hours before delivery, using trial tool blocks.
Integrated Valve Gate and Hot Runner controls plus multiple programmable core pulling circuits.
SPI/SE based isolated I/O, components layout and wirings.
Simplified and practical locking mechanism design featuring long term operation without failure.
Touch less linear transducers featuring long term safe and precise operation.
Beckhoff controller a Multilanguage user-friendly controller featuring SPI and Metric measuring system and full range of settings and control capabilities.
SM-TP machines are manufactured with SPI mold mounting and ejector patterns and can be ordered with optional T-Slots, mounting holes or combination of both.
Ejector system design allows the set-up technician plenty of room and an ergonomic environment to work with the mold-mounted ejector rods.
Electric screw drive screw available. This feature increases the recovery speed and saves cycle time in manufacturing of products, as well as reducing energy consumption and decreasing noise level.
Chen Hsong manufactures more than 15,000 machines a year ranging from 80 up to 7,000 US tons.
The latest technology is used in the fast response gear pumps which ,in combination with the servo motor drive, brings precise, repeatable, and reliable performance.
SPI/CE based full coverage of the barrel and nozzle, brings a safer environment for the operators and set-up technicians.
Ergonomic and user friendly placement of controlling components brings the operator an experience of smooth control over the machine.
Operator friendly design allows accessibility, safety, and a clean working environment.
Two platen design brings larger range of die height, as well as daylight with up to 30% less footprint.
Previous
Next

Specs

Machine ModelClamping Force (Max.)Opening StrokeMaximum DaylightMould Platen (HxV)Space between Tie Bars(HxV)Max. Mould ThicknessMin. Mould ThicknessEjector StrokeEjector Force
Unittmmmmmmmmmmmmmmt
SM7007001.200 – 1.9002.3001.500 x 1.5001.020 x 1.0201.10040028022
SM8508501.250 – 2.00024501.680 x 1.6801.170 x 1.1701.20045030022
SM10501.0501.300 – 2.1002.6001.800 x 1.8001.280 x 1.2801.30050035022
SM12501.2501.500 – 2.3002.8001.950 x 1.9001.380 x 1.2801.30050040022
SM14501.4501.650 – 2.4503.0002.000 x 2.0001.470 x 1.3701.35055040035
SM16501.6501.700 – 2.5003.1002.160 x 2.1201.570 x 1.4701.40060040035
SM19001.9001.700 – 2.5003.2002.300 x 2.2601.670 x 1.5501.50070045045
SM22002.2001.600 – 2.5003.2002.400 x 2.3001.820 x 1.5201.60070045045
SM26002.6001.900 – 2.8003.6002.700 x 2.6001.930 x 1.7301.70080050045
SM30003.0002.100 – 3.0003.9002.800 x 2.7602.020 x 1.8201.80090050045
SM36003.6002.200 – 3.2004.2003.000 x 2.9002.170 x 1.9202.0001.00055055
SM45004.5002.300 – 3.4004.5003.300 x 3.1302.430 x 2.1002.2001.10055055
SM65006.5002.700 – 3.9005.2003.800 x 3.6302.760 x 2.4002.5001.30065080
Specifications are subject to change without notice.
Model IDSwept VolumeShot Weight (PS)Screw DiameterScrew L/D RatioInjection Pressure(Max.)Injection Rate (PS)Screw Rotation Speed (Max.)Screw Stroke
Unitcm3gmmL/Dkgf/cm2g/srpmmm
J12.1641.96983221.906510150400
J22.5452.3169020,31.620599150400
K12.8632.60590221.874578140450
K23.3943.0899820,21.579685140450
N13.7713.43298221.874655130500
N24.7524.32411019,61.487825130500
P15.2274.756110221.874805115550
P26.2205.66112020,21.579958115550
Q16.7866.175120221.874951110600
Q27.9647.24713020,31.5991.116110600
A18.6287.851130221.8341.106100650
A210.0069.10514020,41.5791.282100650
R110.7769.806140221.8341.26595700
R212.37011.25715020,51.5991.45295700
B114.49113.186150221.8341.26595820
B219.72317.94817518,91.3451.72280820
C123.09121.013175221.6301.62983960
C230.15927.44520019,31.2532.12869960
D134.55831.447200221.6302.011651.100
D243.73739.80122519,61.2832.545501.100
E149.30344.866225221.6302.475601.240
E260.86855.39025019,81.3243.056501.240
F167.25061.197250221.6302.839601.370
F281.37274.049275201.3453.435471.370
G189.09481.075275221.6303.922501.500
G2106.02996.48630020,21.3654.667401.500
H116.632106.135300221.6304.518401.650
Specifications are subject to change without notice.

Request a Quote

Choose your options:

    CLAMPING-UNIT
    Unique extractable tiebar design
    Additional core pullers (up to 6 core pullers)
    Airblow on fixed and moving platen
    Parallel core movement
    Parallel ejector movement
    Euromap 70 and 70.1
    Larger maximum mold height
    Automatic lubrication on mold height adjust
    Oil-less bushings for toggle system
    Ejection-on-fly / core-pull-on-fly
    OTHERS
    Up to 60 zones integrated hotrunner System (Euromap 14 standard)
    Additional Power sockets 3-phase 400V 32A and 16A
    Power sockets 2-phase 240V 16A
    Additional Waterflow regulators
    Automation ready
    INJECTION UNIT
    Bi-metallic screw and barrel
    PET or PVC screw features
    Barrel shut-off nozzle
    Hydraulic/pneumatic sequential injection (up to 30 valves)
    Barrel insulation
    Parallel plasticizing
    CONTROLLER
    OPC-UA / Euromap 77

    inquire now Request a Quote
